Construction scheme of two-component polysulfide sealant

一、编制目的  双组份聚硫密封胶施工方案的编制目的是更好的指导施工生产，规范双组份密封胶的施工程序，提高施工效率及有效避免因不规范施工而造成的质量问题。

A compilation purpose of two-component polysulfide sealant construction plan compiling purpose is to guide the construction of production better, specification of two-component sealant construction procedures to improve construction efficiency, and effectively avoid the quality problems caused by the standard construction.

二、适用范围  本施工方案适用于建筑物及渠道伸缩缝的密封处理作业。

Two 、 scope of application this construction scheme is applicable to sealing operation of expansion joints of buildings and channels.

三、双组份聚硫密封胶性能  双组份聚硫密封胶，外观为水状液体胶状物，能够在变形缝里流淌，比较稀，具有耐油、耐水、耐大气老化、耐紫外线、耐冲击、耐磨擦、耐高低温（ -50 ℃ -120 ℃）***、无污染；属低模量，高伸长率等特点。双组份聚硫密封胶具有如下特性:

双组份聚硫防腐密封胶 自流平型    131 6657 0832

Three, two-component polysulfide sealant properties of two-component polysulfide sealant, the appearance of water like liquid jelly, can flow in the deformation joints, relatively thin, with oil, water resistance, ageing resistance, UV resistance, impact resistance, abrasion resistance, high and low temperature (-50 DEG -120 DEG), no po***n no pollution; low modulus and high elongation, etc.. The two-component polysulfide sealant has the following characteristics:

1、具有良好的耐候性、耐久性、长期使用不产生龟裂；

1, with good weather resistance, durability, long-term use, no cracks;

2、对被密封构件具有充分稳定的粘接性及耐久粘接性，对水中混凝土具有长期粘接性；

2, the sealing member has a full and stable adhesive and durable bonding, and has long-term bonding to underwater concrete;

3、水蒸汽透过率极低，双组份聚硫密封胶具有非常好的防水功能；

3, the water vapor transmission rate is very low, two-component polysulfide sealant has a very good waterproof function;

4、不受菌类的侵蚀，对菌类的抵抗性***；

4, free from fungal erosion, excellent resistance to fungi;

5、对密封构件不产生污染，无腐蚀，双组份聚硫密封胶对人体无害。 总之双组份聚硫密封胶适用于金属、混凝土幕墙接缝、地下工程（如隧道、洞涵）、水库、蓄水池等构筑物的防水密封，以及公路路面等伸缩缝的伸缩密封、建筑物裂缝的修补恢复密封。配合比：主剂(A)：固化剂 (B)=100:10( 质量份，标准状态下)，随季节、地域气温的变化。可用固化剂使用量的多少来调节适用期的长短，B 组份的变动范围在10-14 之间。夏天施工时，双组份聚硫建筑密封胶就凝固的时间就快一些，冬天施工时，凝固的就稍微慢一些。

5, no pollution to the sealing component, no corrosion, and the two-component polysulfide sealant is harmless to the human body. In two-component polysulfide sealant is suitable for metal and concrete wall joint, underground engineering (such as tunnel, Dong Han), reservoir, reservoir and other structures of waterproof sealing, and expansion joints of the highway pavement such as sealing, building repair cracks sealing recovery. Mix ratio: main agent (A): curing agent (B), =100:10 (mass fraction, standard condition), with seasonal, regional temperature changes. The amount of curing agent can be used to adjust the length of the applicable period, B components of the range of change between 10-14. In the summer construction, the double component polysulfide construction sealant solidifies faster, and in winter construction solidifies slightly more slowly.

四、双组份聚硫密封胶的施工方法

Four 、 construction method of two-component polysulfide sealant

1、被密封表面的处理：将施工后残留的垃圾杂物清理干净，再用吹风器将浮灰处理干净，若基面潮湿应用喷灯烤干后用钢丝刷刷一遍，以清除烘烤后掉下的水泥屑及尘土。要除去被粘表面的油污及灰尘等杂物，用吹风机吹干净杂物，使涂胶面露出牢固的结构层,接缝表面必须***完全干燥、清洁。表面所有灰尘必须清刷处理干净。必须***被粘表面干燥，平整，以防止粘接不良。金属表面的锈层及保护漆也需除去。

双组份聚硫防腐密封胶 自流平型    131 6657 0832

1, the sealing surface treatment: waste residue after construction debris will be clean, and then dust blower will clean, if the surface wet dry after application of a wire brush again, to remove dust and cement debris falling after baking. To remove the sticky surface of oil, dust and other debris, use blower to clean debris, so that the surface of the coating exposed a solid structure, the joint surface must be fully dry and clean. All dust on the surface must be cleaned and treated. Must be absolutely guaranteed that the sticky surface is dry and smooth to prevent bonding. Rust and protective paint on the metal surface must also be removed.

2、施工前把缝隙的两边1cm处垂直贴上5cm宽的胶带，以防施工中多余的聚硫胶把构筑物表面弄脏。（用过的胶带及时清理）

2, the construction of the gap between the two sides of the vertical 1cm 5cm belt wide, in case the construction of excess polysulfide glue to the surface of the structure of pollution. Clean up (with tape) in time

3 、密封胶的配制：把1桶白色聚硫胶（A组份）与1袋黑色固化剂（B组份）充分搅拌均匀，直到无色差为止。混合比例 A:B=100:10～100:14(质量比)， 将两个组份混合均匀，搅拌时间宜长不宜短，以免因搅拌不均匀造成局部固化不完全而达不到防水密封效果。混合时应防止气泡混入，配制好的双组份聚硫密封胶应在2小时内用完，否则慢慢增稠造成施工困难和降低性能。

3, sealant preparation: 1 barrels of white polysulfide glue (A component) and 1 bags of black curing agent (B component), fully mixing until no color difference so far. Mixing ratio A:B=100:10 ~ 100:14 (quality ratio), the two components will be mixed evenly, mixing time should be long, should not be short, so as not to be uneven mixing caused by partial curing incomplete, and can not reach the waterproof sealing effect. Mixing should prevent bubbles from mixing, the prepared double component polysulfide sealant should be used up in 2 hours, otherwise it will thicken slowly, resulting in construction difficulties and lower performance.

4 、涂双组份聚硫密封胶时，用灰刀或胶枪将配制好的密封胶在接缝两侧先涂抹一层，然后再将双组份聚硫密封胶嵌入缝道中间。操作时应尽量防止夹带气泡进入密封胶中。涂胶时，应该压实，填平密封处，防止气泡混入。

4. When applying the double component polysulfide sealant, use a gray knife or glue gun to coat the sealant on both sides of the joint, and then insert the two-component polysulfide sealant into the middle of the seam. When operating, should try to prevent the entrainment of air bubbles into the sealant. When gluing, it should be compacted and sealed to prevent bubbles from mixing.

5、施工结束后，把缝隙两边的防护胶带取下即可，24小时内应避免水冲雨淋。

5, after the end of the construction, the crevice on both sides of the protective tape can be removed, 24 hours should avoid water rushing rain.

6、施工质量的检查： 密封胶施工完毕后应对接缝进行全面检查，如有漏刮、不平、下垂等应及时修补整齐。双组份聚硫密封胶表干时间为24小时，因此在双组份聚硫密封胶未充分固化前，要注意保护，防止雨水侵入而降低性能。

6, construction quality inspection: sealant construction after completion of the joint should be a comprehensive inspection, such as leakage, uneven, sag, etc., should be repaired in good order. The drying time of the two-component polysulfide sealant sheet is 24 hours, so attention should be paid to the protection of the two-component polysulfide sealant before it is fully solidified to prevent the invasion of rainwater and reduce performance.
